  Product Description: MV 5260-LCD
  Exynos 5260 Hexa Core CPU (Cortex-A15 1.7GHz Dual / A7 1.3GHz Quad)

This solution board is based on Samsung EXYNOS 5260 Hexa Core CPU (Cortex-A15 Dual 1.7GHz / A7 1.3GHz Quad) Processor. It supports 1080p@30fps MPEG2, MPEG4, H.264/H.263, VC1 by using the hardware multi format codec that MCU supports. Also, it supports 2MB L2 Cache for high performance, built-in mass storage LPDDR3 2GB memory, high performance USB 3.0 and eMMC 5.0, 2D/3D Graphic accelerator. For video output, it supports HDMI 1.4a 1080P and WQXGA 2560 x 1600 to higher degree of completion of the real Octal core solution board. It is more high performance and low power than the existing Cortex-A15/A7 and it is full solution board available for a developer to test all specifications such as high performance terminal, Tablet PC, industrial system control terminal ETC.


  1. Features of MV5260-LCD

Materialize MiPi DSI/ CSI !

1. Detachable main CPU Module for mass production
  ㆍParts posting and compact size for mass production
  ㆍMiniaturizing (30x50mm) CPU Module
  Support various extension functions with providing Extension connector
  ㆍPossible to reuse the main CPU Module by modification of Base Board for mass production

※ Proposal : Various kinds of Products can be tested and manufactured for short time with the base board consist of the main CPU module and the chosen part by developers
자세히보기

2. Exynos 5260 Hexa good point
  ㆍSupport eMMC 5.0
  ㆍSupport WQXGA 2560 X 1600 DP PORT
  ㆍSupport Booting UDB without JTAG Emulator
  ㆍSolved the problem of heat and supported low-power for CPU which big/LITTLE all core
  can be controlled
  ㆍSupport external camera interface

3. Google Android OS Porting



ㆍAndroid Version 4.4.2, Kernel 3.4.39
ㆍdebian Linux 7.5 (wheezy), Kernel 3.4.39


ㆍAndroid Version 4.4.2, Kernel 3.4.39 list for offering
- Support ADB based on Eclips development environment USB
- Support Ethernet ADB (Android Debug Bridge) environment
- Camera, DMB, Video, MP3, Headset / Speaker, LCD, Touch, Button
- Support Ethernet, SD/MMC, SDIO WiFi

ㆍdebian Linux 7.5 (wheezy), Kernel 3.4.39 list for offering
- Support SD/MMC
- Support Ethernet
- Support Speaker, USB Mouse, USB Keyboard

4. Equipped with Exynos5260 Hexa Core (Quad A15 1.7 Dual / Quad A7 1.3GHz Quad)
  based on Samsung Core

  ㆍBuilt-in Multi Format Codec (MPEG4/MPEG2/H.264/H.263/VC1) in MCU
  ㆍWQXGA (2560 x 1600) eDP
  ㆍHDMI Out-Put Socket 1.4a 1080 P/I (1920X1080)
  ㆍ2D / 3D Graphics OpenGL ES 1.1, 2.3, 3.0 / OpenCL 1.1 full Profile / OpenVG 1.0.1 / EGL 1.4

5. Equipped with High function USB HOST / Device 3.0
  ㆍ USB Host 3.0 Super-speed (5 Gbps)

6. Equipped with High function, Low-Cost memory device for mass production
  ㆍUsed parts/Sockets and designed for mass production considered manufacture for
  mass production
  ㆍEquipped with LPDDR3 2GB (800MHz)
  ㆍEquipped with eMMc 5.0 (4GB) which is lower cost and high capacity than previous
  NOR Flash

7. 7" Wide TFT-LCD for developing eBook/ luxury car navigation system
  ㆍEquipped with 7"LCD which is best-suited for electronic map
  ㆍEquipped with 7" Wide Type MIPI DSI to LVDS / resolution 1024X600

8. Equipped with Wi-Fi / Bluetooth / GPS Module
  ㆍEquipped with Wi-Fi Module required for Wireless communication (SDIO type) / Bluetooth


9. Equipped with Android essential sensor
  ㆍMagnetic Sensor : AK8975, Gyro & Accelerometer : MPU6500

10. Materialization of high speed USB 3.0 for optimized development environment
    ㆍMaterialization of USB 3.0 Device Interface based on maximum speed 480 Mbps
    ㆍMaterialization of optimized development environment is possible with downloading
   mass storage Linux, Android BSP image rapidly
    ㆍUSB Host / Device 3.0
    ㆍUSB Host 2.0
    ㆍUSB OTG 2.0

11. Support various Boot Mode
    ㆍSD Boot Mode
    ㆍeMMc Boot Mode

12. Equipped with battery only for mobile device for manufacturing mobile device and
  Materialization of rechargeable circuit

    ㆍEquipped with Not the adapter type for simple reference board and training kit but the mobile
   device-only battery and extra battery for manufacturing mobile device
    ㆍMaterialization of battery charge circuit and software which is possible to application on
   mass production mobile device

13. Various Interface giveaway
    ㆍSPI, I2C ,I2S, ADC, UART, Keys, HSIC, PWM, GPIO
    ㆍMIPI - CSI(Camera) , MIPI-DSI(LCD)



 2. Components of MV5260-LCD(EXYNOS 5260 Hexa Core) System Block Diagram


 3. MV5260-LCD Main CPU Module

click!!!


 3-1. Components of MV 5260-LCD System









 4. Components of MV5260-LCD and Peripheral Device

<Components>
ㆍUSB 3.0 / USB 2.0 Host, Device (1.5 / 12 / 480Mbps)
ㆍLPDDR3 (2 GB) / eMMc (4 GB)
ㆍ2D/3D Graphics
ㆍAndroid 4.4.2 / debian 7.5

<Peripheral Device>

GPS (NAVI.)
ㆍMicro Advantec Module
ㆍApply MAT-1316
ㆍBuilt-in ARM7 TDMI
ㆍApplicable area: Navigation


Camera (MIPI CSI)
ㆍFront: 2M Pixel
ㆍBack: 8M Pixel
ㆍApplicable area: Phone, PDA


DP Port
ㆍWQXGA
  (MAX 2560 x 1600)


Wi-Fi / Bluetooth 2.0
ㆍWM-BN-BM-04
ㆍ802.11 b/g/n SDIO Module
ㆍIncluded Bluetooth 4.0



Battery (Option)
ㆍBattery only for mobile device
ㆍVarious 1300mAH capacity
ㆍRecharge
ㆍApplicable area: Whole mobile part









 5. MV5260-LCD Hardware SPEC
ITEM
SPEC&PART
DESCRIPTION
CPU Exynos 5260 Exynos 5260 (Cortex-A15 1.7GHz Dual / Cortex-A7 1.3GHz Quad)
[Cortex-A15 Dual core.
32KB/32KB I/D cache / 1MB L2 cache X2]
[Cortex-A7 Quad core.
32KB/32KB I/D cache / 512KB L2 cache X4]
RAM LPDDR3 Internal 2GByte (800MHz)
NAND Flash EMMC eMMc 5.0 / 4GB
Audio Codec WM8960 Stereo 400mW out-put speaker , MIC IN, Headset
Graphic 2D/3D 2D/3D Graphic Controller
USB 3.0/2.0 USB 3.0 , USB 2.0 Device(OTG)
/ USB Host HSIC
HDMI 1Port 1.4a HDMI Standard 19Pins Connector (1080p)
LCD (MIPI) 7"WSVGA LCD 1024x600 MIPI to LVDS, 7"WSVGA LCD 1024x600
( Multi touch constant voltage way )
MIPI 1Port 4 Lane CH1: Pin Header, only LCD interface
Resolution: MAX 1920 x 1200 WUXGA
eDisplay Port eDP 1Port DP Standard Connector, MAX 2560 x 1600 WQXGA
( Header )
Touch Screen Capacitive
Multi Touch
10 Point Multi Touch Screen Panel

CAMERA
(MIPI CSI)

2Port

4 Lane CH1: Camera Interface Header
2 Lane CH2: Camera Interface Header

Ethernet SMSC9220 10/100Beas-T, Link/ACT LED
SD Slot 1Ports SD Slot 1Ports
PMIC S2MPA01 S2MPA01 (Buck 10 EA /LDO 26 EA )

WI-FI,
Bluetooth

SDIO Type WI-FI 802.11b/g.n, WPA/WPA2 (Type of Module) / Bluetooth 2.0
GPS 1Port MAT-1316, included ARM7 TDMI
Battery
( Option )
5000mAH Battery 5000mAH/3.7V
Charger BQ24167 AC & Battery Switching
UART 4Ports DSUB 1Port, Extension Connector 2Ports, GPS 1Port
Sensor Sensor Magnetic Sensor : AK8975, Gyro
& Accelermeter : MPU6050
ETC Ports I2C, PWM, SPI, ADC, UART, Keys


 6. MV5260-LCD Software SPEC
OS Android 4.4.2, debian 7.5 (Linux Kernel 3.4.39)
Bootloader H/W initialization (UART) (115200)
Image Download USB 2.0 (Device)
Flash eMMc 5.0 (4GB)
Driver

LVDS LCD 7"/Multi Touch ( Support Android) (1024x600), 5Point
USB 3.0 / USB 2.0 OTG
USB Device 2.0
- Debug UART
- GPS
- HDMI 1.4a ( Support only Android )
- Audio Codec (SPK / MIC / Headset)
- I2C / SPI / Magnetic Sensor, Accelermeter
- WiFi (SDIO Type)(Support only Android)
- Bluetooth 2.0 (Support only Android)
- SDHC2.0 memory card
MIPI Camera (Interface Header Type)(Support only Android)
Ethernet 10/100Beas-T Device Driver
Support PWM ( Control of LCD brightness )
Support PMU

Application Camera APP sample giveaway (Android)


 7. Contents of MV5260-LCD CD

1. Schematic(PDF, DSN), Data Sheet of Components
2. Data Sheet of Components (Android, Linux), Korean Manual
3. Provide Device Driver source
4. BSP(Android, Linux) source, Provide Binary Images as following
ㆍ Android Linux O/S porting: Support LCD, Multi Touch
ㆍ Android Version 4.4.2, Kernel 3.4.39 O/S porting
ㆍ Support Ethernet 10/100M based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support MIPI CSI Camera 8M Pixel based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support HDMI 1.4a based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support USB 3.0 Host based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support USB 2.0 Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support SDIO Wi-Fi Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support Bluetooth Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support SD/MMC Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support MIPI TO TFT LCD 7" Driver Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support MIPI TO TFT LCD 7" Multi Touch Driver Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support Audio Codec(SPK,MIC,Headset) Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support Graphic rotation function Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Apply GPS Android based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support Device based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support Video based on Android Version 4.4.2, Kernel 3.4.39
ㆍ Support Boot Loader Binary Image based on debian 7.5 Linux (Kernel 3.4.39)
ㆍ Support Boot Loader Source based on debian 7.5 Linux (Kernel 3.4.39)
ㆍ Support Version Binary Image based on debian 7.5 Linux (Kernel 3.4.39)
ㆍ Support Binary Image based on debian 7.5 Linux (Kernel 3.4.39)
ㆍ Support MIPI TO TFT LCD 7" Driver based on debian 7.5 Linux (Kernel 3.4.39)
ㆍ Support USB 3.0/2.0 Driver based on debian 7.5 Linux (Kernel 3.4.39)
ㆍ Support SD/MMC Driver based on debian 7.5 Linux (Kernel 3.4.39)




1. Various Codec & Parser demo version provides based on StageFright
 (Optional for Commercial version)
2. Streaming solution provides in order to pass the CTS & CMCC test
 (Optional for Commercial version)
3. HEVC(H.265) Decoder demo version provides - upto 1080p
 (Optional for Commercial version)
4. Multiple Video Player APK provides

<MV5260-LCD Multimedia Solution>
- Various Codec and Parser demo version provides based on StageFright Media Framework
- Compatible for Standard Google API
- While playing video, it provides Lower CPU Occupation and Longer battery life time




<MV5260-LCD Streaming Solution>
- CTS and CMCC test supports
- RTP/RTSP optimized
- HTTP Download and Play and Progressive Download supports
- HLS supports

Chinese streaming sites supports
www.iqiyi.com www.youku.com tv.sohu.com
www.tudou.com www.pptv.com www.56.com
v.qq.com m.ku6.com m.3gtv.com
www.pps.tv www.people.com.cn movie.douban.com
video.baidu.com www.pchome.net www.chinabyte.com
www.kankan.com video.sina.com etc


<MV5260-LCD HEVC(H.265) Decoder Solution>

- HEVC(H.265) 1080p 4Mbps real-time playing Supports
- The world-class performance and the market-proven solution

<MV5260-LCD Multiple Video Player Demo APK>
- 3 x 1080p Videos play at the same time.
- 6 x 720p Videos play at the same time


Exynos5260 Codec Support list

1. Video Codecs

Codecs
Specification
Video MPEG-2

ISO/IEC 13818-2 main profile Decoder OMX Component

- 1080P@30fps 40Mbps (MFC User manual)
MPEG-4 SP/ASP

ISO/IEC 14496-2 simple/advanced simple profile Decoder OMX Component

- D1@30fps 8Mbps (MFC User manual)
H.263

ITU-T Rec. H.263 Decoder OMX Component

- D1@30fps 8Mbps (MFC User manual)
H.264 BP, MP, HP

ISO/IEC 14496-10 AVC, ITU-T Rec. H.264 baseline profile, main profile, high profile

(Under Level 4)Decoder OMX Component

- 1080P@30fps 20Mbps (MFC User manual)
VC-1 / WMV9

SMPTE 421M VC-1 Advanced Profile Decoder OMX Component

- 1080p@30fps 45Mbps (MFC User manual)
XVID

XVID Decoder OMX Component

- D1@30fps 8Mbps (MFC User manual)
MPEG-1

ISO/IEC 11172-2 main profile Decoder

- CIF@30fps 2Mbps
WMV 7/8

Microsoft WMV 7/8 Decoder

- VGA@30fps 1Mbps

* Requirement : LICENCEE should Licensee Agreement from Microsoft
DivX 3

DivX 3 Decoder

- D1@30fps 1.5Mbps

* Requirement : LICENCEE should acquire Licensee Agreement from DivxNetworks
DivX 4/5/6

DivX 3/4/5/6/ Decoder OMX Component

- D1@30fps 8Mbps (MFC User manual)

* Requirement : LICENCEE should acquire Licensee Agreement from DivxNetworks

2. Audio Codecs

Codecs
Specification
Audio MPEG-1 Layer I&II

ISO/IEC 11172-3 Audio Layer 1 & 2 Decoder OMX Component

MPEG-1 Layer III

ISO/IEC 11172-3 Audio Layer 3 Decoder OMX Component

WMA9 Pro

WMA 9 PRO Decoder OMX Component, support DownMix

WMA9 Standard

WMA 9 Standard Decoder OMX Component, support DownMix

AAC LC

ISO/IEC 13818-3 Audio Advanced Audio Coding Low Complexity Profile Decoder OMX Component, Support ONLY mono / stereo

AAC HE v1/v2

ISO/IEC 14496-3 High Efficiency AAC Profile/High Efficiency AAC v2 Profile Decoder OMX Component

Vorbis

Vorbis Decoder OMX Component

FLAC

Free Lossless Audio Codec Decoder OMX Component, support ONLY 16bit stereo

PCM

Support 16bits

AC-3(Downmix)

Dolby AC-3 Downmix Decoder OMX Component

* Requirement : LICENCEE should acquire Licensee Agreement from DOLBYLAB

3. Container Parsers

Container Parsers
Specification

Audio

Container
MP4 ISO/IEC 14496-1 MPEG-4 System Format Parser
3GP 3GP is defined by the 3GPP for 3G UMTS multimedia services
MOV QuickTime File Format, supports only MP4 File Compatible Format (H.264/MPEG-4 and AAC audio)
AVI Audio Video Interleave Format Parser
MPG MPEG-2 PS System Format Parser
VOB

Container format in DVD-Video media (MPEG Program Stream Format),

support only MPEG-2 video and MPEG-1/2 Audio layer II audio/AC-3 audio
MKV Matroska Format Parser, Supports only video and audio
OGM System Format for Ogg (Video : MPEG-4, H.264 / Audio : Vorbis, AC-3, MP3)
WMV/ ASF Microsoft WMV / ASF Parser
MPEG-2 TS MPEG-2 Transport Stream Parser

Audio

Container
MP3 MPEG-1/2 Layer 3 Container
AAC / HE AAC MPEG-2/4 AAC LC, AAC+ v1, HE AAC
MKA Matroska Audio Format
OGG Vorbis Format
FLAC Free Lossless Audio Codec
WMA Windows Media Audio Format
WAV WAVE Format

4. Container and Codecs Combination



 8. Package List(MV5260-LCD)
MV5260-LCD
(front)
MV5260-LCD
(side)
Power Supply
USB Cable

Serial Cable
MV5260-LCD CD
GPS Receiver
Camera Module


SDIO Type WIFI
Bluetooth 2.0
Box

 9. Various applied area of MV5260-LCD



 10. Development Tool Environment

 11. Technical Support

Technical Q&A for MV5260-LCD

ㆍ Technical support team for Reference Board (6 experts) !!


ㆍ Quick & accurate After sales Service !


ㆍ Technical support by E-mail for Solution board problem


  (E-mail : tech@mvtool.co.kr / tst@microvision.co.kr )
